PPW 3000 Double Tilt High Speed Scale for Control of Components Completeness
details
| Double tilt weight sensing device | for completeness control |
| Model | PPW 3000 |
| Technical Data | |
| Drive of weighing plate | electro-pneumatical |
| Control system | microcomputer |
| Time of scale | 0,2 s |
| Weighing cycle | 3,5 s |
| Measuring range | 5 - 2000 grams |
| Smallest detectable weight tolerance | 0,8 g (1% of FS weight) |
| Dimension weighing plate | |
| Standard version | 500 x 375 x 100/50 mm |
| other dimensions | according to customer's requirements |
| Direction of tilting | correct parts - out of tolerance parts |
| Power supply | 115 / 230 VAC 0,15 / 0,3 A |
| Plug connection to die casting machine | Harting plug, HAN-E, 6-pole |
| Connection cable | 5m (standard) |
| System pressure for weighing plate | 4 - 6 bar max. |
| Description |
| Setup via keyboard. Display indicates part weight in grams, tolerances in grams or % of total weight and error messages. Digital automatic Zero compensation after each weighing cycle. Relay outputs. Weighing plate stainless steel with 100/50 mm high side walls. |
Option
Serial interface for PC, printer, etc.
Application
- for control of completeness after assembly
- manufactoring reports
- quality control
Advantages:
- very fast weighing process
- user-friendly scale
- robust construction
| Delivery time | on request |
| Price | on request |
Subject to alterations.
