Manufacturer · Cold chamber die casting · Italy

Used Idra die casting machines OL, NEO and Giga Press from Travagliato

IDRA, based in Travagliato near Brescia, has built die casting machines since 1946 and has been part of the LK Group since 2008. Today's range runs from the compact XPress at 300 t to the Giga Press at 9,000 t of clamping force for large structural castings. On the used market, most machines belong to the OL family. The product list shows the used Idra machines FISS is currently offering.

  • since 1946Travagliato (BS), Italy
  • 300–9,000 tClamping force, current range
  • since 2008Part of the LK Group

Machine you need not listed? Send FISS a search request

Used Idra OL 3500 die casting machine from a FISS offer

Idra OL 3500 (offer KK1678) · Photo: FISS

Filter products

Knowledge · Idra

Buying a used Idra: types, technology and inspection points

In die casting, Idra is best known for large cold chamber machines. It delivered its first 2,000 t machine in 1966 and its first 4,000 t machine in 1993, and under the Giga Press name, introduced in 2019, it now builds machines of up to 9,000 t. Most Idra machines traded second-hand are mid-sized and large OL models. This page sets out the series, explains the type codes and lists the assemblies worth inspecting on a used Idra.

01 · Overview

Idra at a glance

Manufacturer
IDRA S.r.l. (brand: IDRA Group), Travagliato (Brescia), Italy
Founded
1946 by Adamo Pasotti
Ownership
part of L.K. Technology Holdings (LK Group) since 2008
Current series
XPress, OL CS, NEO and Giga Press (NEO 5500 to NEO 9000)
Clamping force
300 t (XPress) to 9,000 t (NEO 9000), as stated by the manufacturer
Milestones
1966 first 2,000 t machine, 1973 3,200 t, 1993 4,000 t, 2018 OL 5500 CS, 2019 OL 6200 CS
Control system
currently Inject Computer 3.0 with an 18-inch touch screen; older machines run earlier generations
Typical castings
aluminium structural parts, battery housings and rotors for electric and hybrid vehicles, body-in-white parts

How to read an Idra type code

On today's large machines the number gives the clamping force class in tonnes: a NEO 9000 is a 9,000 t machine and the OL 5500 CS a 5,500 t machine. For any individual machine, the kN rating on the nameplate and data sheet is what counts.

Used OL machines carry suffixes such as S, CS, PRP, ST or DG, for example OL 1100 S, OL 420 CS or OL 900 PRP. These denote different generations and specifications, so have the configuration confirmed against the serial number rather than inferring it from the suffix.

OL/Mg denotes hot chamber machines for magnesium, such as the OL/Mg 320 or OL/Mg 560. Idra's current product pages no longer list a hot chamber series.

02 · Series

Idra series: from XPress to Giga Press

The current programme is split into four lines. Many used machines come from earlier OL generations whose specifications differ from today's data sheets. For the basic differences between toggle and two-platen clamping, see our article on toggle vs. two-platen clamping systems.

Compact · toggle

Idra XPress

300–900 t Clamping force

  • Compact machine with a rigid toggle clamping system and tie bar extraction
  • Idra S injection system; brushless motors drive the hydraulic pump
  • Inject Computer 3.0 control

Smallest clamping force band in the current Idra range

Mid-size to large

Idra OL CS

420–4,200 t Clamping force

  • Injection via a closed-loop Parker meter-out proportional valve, with real-time pressure control
  • Temposonics position sensing on the intensifier and laser measurement of moving platen foot wear
  • Rapid Die Change for automated die changes; DCP pump system to cut energy use

Seen on the used market as, for example, the OL 420 CS

Efficiency · structural casting

Idra NEO

340–4,400 t Clamping force

  • 5S injection: regenerative, closed loop, with an auxiliary servo pump for recharging
  • Injection speeds up to 10 m/s; closed-loop intensifier for final pressure
  • Designed for structural parts, battery boxes and rotors for electric and hybrid vehicles

Large machines

Idra Giga Press

5,500–9,000 t Clamping force

  • NEO 5500
  • NEO 6100
  • NEO 8000
  • NEO 9000
  • For large body and structural castings; Idra quotes parts of up to 250 kg
  • Developed from the OL 5500 CS (2018) and OL 6200 CS (2019)
  • Hydraulics with Drive Control Pump (DCP)

Example: NEO 9000 = 9,000 t clamping force class

Clamping force bands of the current Idra series

XPress300–900 t
NEO340–4,400 t
OL CS420–4,200 t
Giga Press5,500–9,000 t
03,0006,0009,000 t

Linear scale; manufacturer figures in tonnes (as of 11/2026). For used machines, the kN value on the nameplate and data sheet applies.

03 · Buying guide

What to check on a used Idra

With Idra machines, much depends on which OL generation a machine belongs to and how it has been upgraded since. Clarify these points before you commit.

  • Nameplate, serial number and suffix

    Record the full designation (e.g. OL 900 PRP or OL 1100 S), year of build and clamping force in kN. The serial number lets you check the original specification and scope of supply with the manufacturer.

  • Control generation

    Establish whether Inject Computer 3.0 or an earlier generation is fitted, which PLC sits behind it, and whether shot curves can be stored and exported. On older operator PCs, check spare parts availability and data backups.

  • Injection valve and position sensing

    Ask for test shots with recorded shot curves. Watch for unstable second-phase speed or slow pressure build-up at the intensifier. Background: shot curves and process monitoring.

  • Clamping unit and platen feet

    Inspect toggle pins and bushes, tie bars and platen parallelism. On OL CS machines, the laser platen foot measurement records wear of the moving platen's sliding shoes, so ask to see the readings.

  • Hydraulics, pumps and accumulators

    Newer machines use the DCP pump system with speed-controlled motors; older ones have conventional pumps. Review the oil analysis, look for leaks and ask for the accumulator inspection records.

  • Die change and tie bar extraction

    Check whether Rapid Die Change or hydraulic tie bar extraction is fitted and working. Both affect set-up times and how the machine integrates into your cell.

  • OL/Mg hot chamber: shot end and cover gas

    On magnesium hot chamber machines, the condition of gooseneck, nozzle and plunger matters, as do the furnace and cover gas supply. See hot chamber: gooseneck, nozzle, plunger.

  • Large machines: foundations and relocation

    On large OL machines and the Giga Press, foundations, transport dimensions and dismantling drive a large share of the project effort. Plan the move early: relocation: dismantling and transport.

04 · Services

Services for your used Idra

FISS supports the purchase and sale of used Idra die casting machines, from machine selection through dismantling and transport to recommissioning.

Practical guide to relocation: Relocation: dismantling and transport

05 · FAQ

Frequently asked questions about Idra

Who owns Idra today?

IDRA S.r.l., headquartered in Travagliato near Brescia, has been part of the LK Group (L.K. Technology Holdings) since 2008. The company remains headquartered in Italy.

What is the Idra Giga Press?

Giga Press is Idra's name for its large machines from 5,500 to 9,000 t of clamping force (NEO 5500 to NEO 9000). They cast large aluminium structural parts, for example for electric vehicle bodies. The line began with the OL 5500 CS in 2018 and the OL 6200 CS in 2019.

Does Idra make hot chamber machines?

The current product pages list XPress, OL CS, NEO and Giga Press, with no hot chamber series. On the used market, however, you will find OL/Mg hot chamber machines for magnesium, such as the OL/Mg 320 and OL/Mg 560.

What does the number in OL 900 PRP or NEO 9000 mean?

It indicates the clamping force class in tonnes, so a NEO 9000 is a 9,000 t machine. The exact kN rating is given on each machine's nameplate and data sheet and may differ from the class number on older generations.

Which control system does a used Idra have?

Current machines run Inject Computer 3.0, the third generation of Idra's operating software. Older OL machines have earlier versions, so confirm the version and PLC before you buy.

Can I sell my Idra machine to FISS?

Yes. Send the type designation, year of build, clamping force and photos via our purchase page. FISS reviews the details and gets back to you on the next steps.

Contact

Looking for a specific Idra?

Tell us the series, clamping force and application, and we will come back to you with suitable machines from our network.

As of November 2026. Technical data based on public information from IDRA and the LK Group; clamping forces as stated by the manufacturer in tonnes. For an individual machine, the nameplate and data sheet apply. Sources:
